XD-PR-024

Date:2023-02-16   Author:XINDA MOTOR
XD-PR-024

XD China Manufacturers pinion 3 phase motor planetary reducer gearbox for marine


Essential details


Warranty:3 years
Applicable Industries:Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Servo Motor
Weight (KG):1.3 KG
Customized support:OEM
Gearing Arrangement:Planetary
Output Torque:Can be customized, Depended on the servo motor
Input Speed:Can be customized, Depended on the servo motor
Output Speed:Can be customized, Depended on the Ratio
Place of Origin:Shandong, China
Brand Name: XD
Product name:Planetary Gearbox
Ratio:3,4,5,6,8,10
Input interface:According to motor output
No-load torque at 20oC (Nm):≤0.1Nm
Normal Input Speed:1500r/min
Max. Input Speed:3000r/min
Max. Radial Load:8500N
Max. Axial Load:5800N
Noise:≤72db

Protection grade (IP):IP54



Product Description
Product Name
planetary gearbox
Brand Name
XD
Applicable Industries
Servo Motor
Gearing Arrangement
Planetary
Ratio i
3,4,5,6,8,10
Input interface
According to motor output
Max. radial load (N)
8500
Max. axial load (N)
5800
Rated input speed (r/min)
1500r/min
Max. input speed (r/min)
3000r/min
Noise (db)
≤72db
Backlash – Class P2 (arcmin)
≤8arcmin
No-load torque at 20oC (Nm)
≤0.1Nm
Operating temperature (℃)
-15 to +40℃
Service life (h)
≥20,000h
Protection grade (IP)
IP54
MOQ
1
