Rated power 额定功率(KW):

8.5

Peak power峰值功率 (KW):

15

Rated Voltage 额定电压DC(V):

72

voltage range电压范围 DC(v) :

Rated current 额定电流(A):

147

Peak current最大允许电流(A):

350

Rated speed 额定转速(r/min):

3600

Peak speed最高转速(r/min):

5000

Rated torque 额定扭矩(N.m):

22.5

Peak torque 峰值扭矩(N.m):

90

Efficiency电机的效率%:

Duty工作制 :

S9

weight重量kg):

冷却方式 cooling method

自然冷却

air cooling

绝缘等级 insulation grade

H
